Key Features
• Speed range of 200-14000rpm, max. RCF 18620×g
• Precise control of speed and time separately
• Easy operation with intuitive menu and easy-to-read display
• Maintenance-free brushless DC motors
• Pulse operation for quick spins
• Rotor capacity: Hematocrit rotor
• Hematocrit rotor:24 capillary max. speed:12000rpm
| Specifications | DM1424 |
| Speed Range | 200-14000rpm,
increment: 10rpm |
| Max. RCF | 18620×g |
| Speed Accuracy | ±20 rpm |
| Rotor Capacity | 2 type |
| Run Time | 30sec-99min/Continuous |
| Motor | Brushless DC moto |
| Display | LCD |
| Safety Devices | Door interlock,Overspeed detector;Over-temperature detector, Automatic internal diagnosis, Automatic rotor identification |
| Power | Single-phase,
220V-240V,50Hz/60Hz, 5A;110V-120V,50Hz/60Hz, 5A
500W |
Acceleration
/Braking time [Sec] | 30s↑30s↓ |
| Dimension [D×W×H] | 280×364×274mm |
| Weight | 10kg |
| Certification | CE cTÜVus FCC MCA |
| Advanced Features | Speed/RCF switch; Short-time run function; sound-alert function |
