Mode | NR145 | NR20XE | NR10QC | NR200 | NR110 | NR60CP |
Illuminating | 45°/0° | 45°/0° | 8° /d | 8° /d | 8°/ d | 8°/ d |
Aperture | Φ8mm | Φ20mm | Φ4mm | Φ8mm | Φ4mm | Φ8mm flat aperture; Φ4mm tip aperture |
Detector | Silicon photoelectric diode |
Locating | Illuminating Locating/Cross Locating |
Measurement End Face | Large stable end face and small concave-convex end face | Large Stable End Face | Large stable end-face and small concave-convex end-face | Large stable end-face and small concave-convex end-face | Large stable end-face and small concave-convex end-face |
Color Space | CIEL*a*b*C*h* CIEL*a*b*
CIEXYZ | CIEL*a*b*C*h*; CIEL*a*b*; CIEXYZ | CIE-La*b*C*H CIE-L*a*b
CIE-XYZ | CIEL*a*b*C*h* CIEL*a*b* | CIEL*a*b*C*h* CIEL*a*b*
CIEXYZ | CI E L AB，XYZ，LCh，CI E RGB，CI E LUV |
Color Difference Formula | △E*ab △L*a*b* △E*C*h* | △E*ab; △L*a*b*; △E*C*h* | △E*ab | △E*ab △L*a*b △E*C*h | △E*ab △L*a*b* △E*C*h* | ΔE* ab, ΔE( h) , ΔE* uv, ΔE* 94, ΔE*cmc ( 2: 1) , ΔE*cmc ( 1: 1) , ΔE* 00 |
Light Source | D65 | D65，A，C，D50，F2，F6，F7，F8，F10，F11，F12 |
Light Source Device | LED blue light excitation |
Errors Between Each Equipment | ≤0.80ΔE*ab | ≤0.50ΔE*ab | ≤0.20 ΔE*ab | ≤0.50ΔE*ab | ≤0.80ΔE*ab | ≤0.20ΔE*ab |
Storage | 100pcs standards 20000pcs samples |
Repeatability | ΔE*ab 0.08
Average of 30 measurements of standard white plate | ΔE*ab 0.08 Average of 30 measurements of standard white plate | ΔE* ab 0. 03 (Average of 30 measurements of standard white plate within 5s) | ΔE*ab 0.08
Average of 30 measurements of standard white plate | ΔE*ab 0.08
Average of 30 measurements of standard white plate | ΔE* ab 0. 03 (Average of 30 measurements of standard white plate within 5s) |
Lamp Life | 5 years, more than 1.6 million measurements |
Power source | Rechargeable lithium-ion battery 3.7V@3200mAh |
Charging Time | 2 hours (First time 8 hours--100% electricity) |
PC Software | CQCS3 Software |
Printer (optional) | Miniature thermal printer | Miniature thermal printer, Powder Test Box | Miniature thermal printer | miniature thermal printer, powder test box |
Language | Chinese/English |
Weight(g) | 500 | 500 | 500 | 500 | 450 | 500 |
Dimension(mm) | 205*67*80 | 205*67*80 | 205*67*80 | 205*70*100 | 205*67*80 | 205*67*80 |
