The HQD digital meter is ideal for any of the following measurement parameters as a pH meter, a mV/RedOx/ORP meter, an Ion Selective (ISE) meter, a Dissolved Oxygen (DO) meter, a Biochemical Oxygen Demand (BOD) meter, a conductivity meter for measuring electrical conductivity, salinity, resistivity, or total dissolved solids (TDS), in wastewater, drinking water or general water quality applications, soil, and food or beverages applications. A wide range of IntelliCAL electrodes, cell, probes and sensors are available to perform accurate measurements in any sample media types.
HQ430D Single Input Multi-Parameter Meter
Designed for water quality experts, the Hach HQ430D Laboratory Multi-Meter is an advanced laboratory meter that takes the guesswork out of measurements. HQD laboratory meters connect with smart IntelliCALⓇ electrodes that automatically recognize the testing parameter, calibration history, and method settings to minimize errors and setup time. The advanced HQD Laboratory Meter is designed to withstand years of continuous lab use. HQD bench meters feature a simple user interface that does not require manuals or training to operate.
Flexible Laboratory bench multi Meter for efficient water quality parameters testing
Intuitive user interface for simple operation, reliable and accurate results
Trust your measurements - IntelliCAL smart probes store all calibrations in the probe
Enhance data connectivity with easy to read results
Improve productivity and save laboratory space
Automatic Buffer Recognition | Yes |
Backlight | Yes |
Barometric Pressure Measurement | Automatic compensation of DO when using an LDO or LBOD probe |
Calibration | Demal (1D/ 0.1D/ 0.01D); |
Molar (0.1M/ 0.01M/0.001M); | |
NaCl (0.05%; 25µS/cm; 1000µS/cm; 18mS/cm); | |
Standard sea water; | |
User defined | |
Calibration Intervals/Alerts/Reminder | Off, selectable from 2 hours to 7 days |
Communication | Integrated USB type A (for USB 2.0 flash memory device, printer, keyboard) and Integrated USB type B (for PC) |
Compliance Certifications | CE.WEEE |
Conductivity measurement | Yes |
Conductivity Measurement Range | 0.01 µS/cm - 200.0 mS/cm |
Conductivity resolution | 0.01 µS/cm - 0.1 mS/cm upon selected measuring range |
Contents | Meter Only |
Custom Calibration Standards | Yes |
Data Export | Download via USB connection to PC or flash memory device. Automatically transfer entire data log or as readings are taken. |
Data Memory | 500 records/FIFO |
Data Storage | Automatic, GLP ISO compliant reading data stored with calibration details. |
Dimensions | 859 x 175 x 235 mm (3.38 x 6.88 x 9.25 in.) |
Display | Detailed mode/Large mode |
Display Type | 440 x 160 pixel LCD with backlight illumination |
DO Measurement Range | 0.1 - 20.0 mg/L (ppm) 1 - 200% saturation |
DO Resolution | 0.1 |
DO sensor calibration | • 100% (water-saturated air (100%) calibration |
• 100% with 0 (water-saturated air (100%) calibration with 0 point | |
• mg/L (calibration with a specified dissolved oxygen concentration (mg/L) solution) | |
• mg/L with 0 (calibration with a specified dissolved oxygen concentration (mg/L) solution with 0 point) | |
• Factory (calibration with the default LDO calibration) | |
Electrode stand | Optional |
GLP Features | Date; Time; Sample ID; Operator ID |
Instrument | Bench |
IP Rating | IP54 (Resistant to spray of water; Dust-proof) |
ISE Direct Measurement Range | Yes |
ISE Electrode Calibration | 2 - 5 points |
Kit? | No |
Languages | English, French, German, Italian, Spanish, Danish, Dutch, Polish, Portuguese, Turkish, Swedish, Czech, Russian |
Lock Function | Continuous / Auto-stabilization ("press to read") / At Interval |
Measurement Method | Probe specific programmed method settings |
Model | HQ430D – Multi/1 Channel |
mV Measurement at Stable Reading | Yes |
mV Measurement Range | -3000 |
mV Resolution | 0.1 mV |
Needed Cable Length | NA |
Operating Error Messages | Clear text error messages displayed |
Operating Humidity | 90 % relative humidity (non-condensing) |
Operating Interface | Soft Touch Keypad |
Operating Temperature | 0 - +60 °C (32 - 140 °F) |
ORP Electrode Calibration | Predefined ORP standards (including Zobell's solution) |
Parameter | pH/Oxydo Reduction Potential (ORP) |
Conductivity/Total Dissolved Solid (TDS)/Salinity/Resistivity | |
Dissolved Oxygen (DO) | |
Biochemical Oxygen Demand (BOD) | |
Ion Selective Electrode (ISE): Ammonia, Ammonium, Chloride, Fluoride, Nitrate, Sodium | |
PC Data Transfer Software | HQD Series Meter Data Transfer Utility |
pH Buffer Sets | Color-coded: 4.01, 7.00, 10.01 pH; |
IUPAC: 1.679, 4.005, 7.000, 10.012, 12.45 pH | |
DIN: 1.09, 4.65, 9.23 pH | |
User-defined custom buffer sets | |
pH Electrode calibration | 1 - 3 Calibration points |
Calibration summary data logged and displayed | |
pH Measurement Range | 0 - 14 pH |
pH Resolution | Selectable: |
0.001/0.01/0.1 pH | |
Printer | Yes, Optional |
Probes included | None |
Resistivity Measurement | 2.5 Ω.cm - 49 MΩ.cm |
Resistivity Resolution | 0.1 |
Salinity Measurement Range | 0 - 42 (ppt) (‰) |
Salinity Resolution | 0.01 (ppt) (‰) |
Sensor A | NA |
Sensor B | NA |
Sensor C | NA |
Sensors | Sensor A: NA |
Sensor B: NA | |
Sensor C: NA | |
TDS Measurement Range | 0.00 mg/L - 50.0 g/L as NaCl |
TDS Resolution | 0.01 mg/L - 0.1 g/L upon measuring range. |
Temperature Compensation | Automatic Temperature compensation for pH |
Temperature Measurement | °C or °F |
Temperature Range | ‘-10°C - 110 °C |
Temperature Resolution | 0.1 |
Type of measurement | Lab Water Quality applications. |
Weight | 750 g (1.65 lb) without batterie; 850 g (1.87 lb) with batteries |
What's included? | Includes: meter, 4 AA batteries, universal power adapter, USB cable for data transfer, quick start guide and user manual |
