In the workroom the hot air is convective naturally and cyclically.
Digital display microcomputer intelligent PID temperature
New anti-hot handle.
| model | WP-25A/WP-25AB |
| Cycle Mode | Natural convection |
| Function | Temp. Range | RT+5-65℃ |
| Temp. Resolution Ratio | 0.1℃ |
| Temp. Motion | ±0.5℃ |
| Temp. Uniformity | ±2.0℃ |
| Structure | Inner Chamber | B model: mirror stainless steel; without;B model: High strength galvanized sheet |
| Outer Shell | cold rolling steel electrostatic spraying exterior |
| Insulation layer | High quaility rock wool board (with CE) |
| Heater | Nickel chromium alloy heating wire |
| Power rating | 0.18kW |
| Exhaust hole | φ28mm top (with function of test hole) |
| Controller | Temp. control mode | Two temperature section intelligent PID |
| Temp. set mode | Touch button setting |
Temp. display mode | Measuring temperature: display on the four digital tubes upper row ； setting temperature: display on the lower row |
| Timer | 0-9999min(with timing wait function) |
| Operation function | fixed temperature operation, timing function, auto stop |
| Additional function | Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory |
| Sensor | PT100
|
| Safety device | over temperature sound-light alarm |
| Specification | Inner Chamber siz e(W*L*H)(mm) | 260*260*260 |
Exterior size (W*L*H)(mm) | 380*455*568 |
Packing size (W*L*H)(mm) | 500*530*657 |
| Volume | 18L |
| Shelf number | 6 |
| Load per rack | 15kg |
| Shelf space | 29mm |
(50/60HZ)Current rating | AC220V/0.8A |
| NW/GW (kg） | 27/35 |
| Accessory | Shelf | 2 |
| Optional accessories | shelf,Programmable controller |
