Large LCD screen and PID controller design. PID microprocessor is used to control temperature and air,meanwhile,the temperature of box ,water and door are separately controlled by three probes to ensure high accuracy. ( Air jacket is equipped with two probes to control door temperature and main body temperature.)
Features
Large LCD screen and PID controller design. PID microprocessor is used to control temperature and air,meanwhile,the temperature of box ,water and door are separately controlled by three probes to ensure high accuracy. ( Air jacket is equipped with two probes to control door temperature and main body temperature.)
Flexible switch, each working status has LCD indication.
Alarm function for over-heating, lack of water, unaspirated, ensuring the safe operation of the equipment.
Equipped with sterile air filtration devices and UV light system to reduce pollution.
Natural evaporation for humidification, so that the chamber can maintain good humidity and the humidity can be displayed on screen.
Equipped with leakage protection and auxiliary thermostat.
RS485/232 connector
CO2 pressure releasing valve
Wireless alarm system (SMS alarm system)
HEPA filter system
Automatic humidification system
90℃ High temperature sterilization
Model | LCI-85/LCI-85T | LCI-165/LCI-165T | LCI-270/LCI-270T |
Chamber Volume | 85 | 165L | 270 |
Temperature Range | RT+3~60℃ | ||
Display Resolution | 0.1℃ | ||
Temperature Fluctuation | ≤±0.2℃ | ||
Temperature Uniformity | ≤±0.3℃ | ||
CO2 Range | 0 ~20% | ||
CO2 Control Resolution | ±0.1%(imported sensor) | ||
Humidity Method | Natural Vaporization | ||
Power Supply | AC220V,50HZ | ||
Power Rating | 600W | 900W | 1400W |
Chamber Size (W×D×H)cm | 40×42.5×50 | 50×51×65 | 60×60×75 |
Exterior Size((W×D×H)cm | 55×57×80 | 65×73×103 | 72×75×110 |
Net/Gross Weight(kg) | 59/92 | 83/120 | 132/165 |
