High accuracy, high performance stepper motor ensures accuracy and repeatability, eliminating manual pipetting errors
Key Features
• A motor driven digital control pipette with multifunction
• 2 buttons handle all operational settings
• Light weight, ergonomic design, small body dimension for easy handling that guarantees fatigue free pipetting
• Pipetting, Mixing, Stepper and Dilution(Only dPette+)
• Pipetting, Mixing(dPette)
• Adjustable speeds for aspiration and dispensing
• Li-ion battery and dual charging modes enable longer operation time
• Self calibration – dPette can be connected to a PC via. USB for calibration by the user. Third party calibration is not required
Volume Range μL | Increment μL | Test Volume uL | accuracy error | precision error | ||
uL | % | s.d.uL | CV% | |||
0.5-10uL | 0.01uL | 10 1 | ±0.10 ±0.035 | ±1.0 ±3.5 | 0.05 0.03 | 0.5 3.0 |
5-50uL | 0.1uL | 50 5 | ±0.40 ±0.15 | ±0.8 ±3.0 | 0.15 0.125 | 0.3 2.5 |
30-300uL | 1uL | 300 30 | ±1.8 ±0.9 | ±0.6 ±3.0 | 0.6 0.21 | 0.2 0.7 |
100-1000uL | 5uL | 1000 100 | ±6.0 ±3.0 | ±0.6 ±3.0 | 2.0 0.6 | 0.2 0.6 |
dPette+ | ||
Cat. No. | Volume | Power supply |
7016201001 | 0.5-10μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz | ||
7016201002 | 5-50μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz | ||
7016201003 | 30-300μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz | ||
7016201004 | 100-1000μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz | ||
Economic dPette | ||
Cat. No. | Volume | Power supply |
7016001001 | 0.5-10μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz | ||
7016001002 | 5-50μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz | ||
7016001003 | 30-300μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz | ||
7016001004 | 100-1000μl | USA plug,100V-220V/50Hz/60Hz |
Cn plug,100V-220V/50Hz/60Hz | ||
Euro plug,100V-220V/50Hz/60Hz | ||
UK plug,100V-220V/50Hz/60Hz |
