Platelet Incubator are suitable to store blood platelet, biological reagent and chemical products for hospitals, blood stations, research institutes and university labs.
Wide temperature range :10℃~32℃ambient temperature can reach 20~24/2~40℃.
Accurate Temperature control technology to make the temperature maintain 20℃~-24/2~40℃and adjustment accuracy 0.1 °C.
The range of fluctuations can be controlled in ±1℃. According to the ring temperature and inner cabinet temperature, intelligent control refrigeration and heating.
304 stainless steel inner chamber for friendly using and easy cleaning.
Double transparent insulation glass door,filled with inert gas ensure the cooling performance.
Build-in back-up battery to display temperature and to operate audible and visual alarm system for up to 72 hours without AC power.
Visual and audible alarm system:High/low temperature, Thermostat failure alarm,Low battery alarm,Power failure alarm,Door ajar alarm.
Power failure protection: turn on delay of the cooling system when power failure,restart delay protection.
Keyboard lock, password protection to avoid set parameter randomly.
Disinfection with UV, can set disinfection time freely, the UV light would off while door open to protect human body.
4 casters with stopper for easy moving and fixation.
Power switch button on the back, more convenient for operation.
Japan imports oscillating slide for long service life and low sound
Temperature printer can be set according to customer needs, monitoring equipment temperature change at any time
Embedded handle,Easy to open
Wide voltage design: 198V~242V available.
Build-in back-up battery: 72 hours power failure alarm.
Large digital display for easy of observation
5 visual and audible alarms.
Model | HMDC-10 |
Capacity(L/cu.ft) | 10 |
Bloodbags(450ml)/Drawer | 20 /10 layers |
NT./GT.(kg) | 85/108.5 |
Exterior size(W*D*H)(mm) | 520*640*1290 |
Interior size(W*D*H)(mm) | 432*462*728 |
Package size(W*D*H)(mm) | 575*690*1450 |
CBM | 0.58 |
20GP/40GP/40HQ | 32/68/68 |
High/low temperature | Y |
Power failure | Y |
Sensor malfunction | Y |
Low baterry | / |
Door ajar | Y |
Power failure backup system(alarm) | 72h |
Caster | Y |
Outer door / Type | 1(Foamed glass door) |
Test hole | Optional |
Light | UV Light |
Temperature recorder | Optional |
Certification | ISO,9001,13485,14001,CE |
