LAW Ultrasonic Milk Analyzer Laboratory Model

LAW Automatic Milk Analyzer with built-in windows system, with external keyboard. It could be used to test milk, goat milk, yogurt, oat milk and other milk samples. At the same time, it can expand multiple detection indicators such as ph, conductivity, total solids, etc. And can expand various functions such as milk weighing scale, scanning code tracking, which is convenient for tracking and is mostly used in laboratories, dairy enterprises, medium-sized milk collection centers, etc.

Inquiry
(+86)010-5653 8958
  • Product description
  • Product parameter
  • Product video

LAW Ultrasonic Milk Analyzer Laboratory Model


LAW Automatic Milk Analyzer with built-in windows system, with external keyboard. It could be used to test milk, goat milk, yogurt, oat milk and other milk samples. At the same time, it can expand multiple detection indicators such as ph, conductivity, total solids, etc. And can expand various functions such as milk weighing scale, scanning code tracking, which is convenient for tracking and is mostly used in laboratories, dairy enterprises, medium-sized milk collection centers, etc.


Product Features

  • User-friendly ultrasonic milk analyzer: simple in operation, maintenance, calibration and installation;

  • Designed for use in Laboratories and Milk Collection Centers;

  • Integrated 7" fully functional display;

  • Cleaning with two peristaltic pumps;

  • Portable and compact design;

  • Very small quantity of milk required;

  • Low power consumption;

  • No use of hazardous chemicals;

  • Measuring accuracy adjustment can be done by the user RS232 Interface;

  • ESC POS Printer Support;

  • Two samples self-calibration;

  • Easily readable results;

  • Possibility of connecting weighing scale;

  • Possibility of connecting pH probe;

  • Integrated pH and conductivity measuring;

  • Function Real time clock;

  • USB;

  • USB flash drive;

  • One year full warranty.

 *LW Series can be connected toward weighting scale. If you want to request this option, please Contact us.



Technical Parameters

Sample vоlume5-20 ml
Measurement speed60/30 sec.
Sample temperature5˚ C – ˚40 C
Humidity0 – 80 % RH
InterfaceRS 232 Port
Overall Size (W x D x H)200/250/230mm
Mass/kg 8 kg
AC supply voltages95-250 V
DC power supply12V

Measuring Parameter

ComponentRangeAccuracy
FAT0% – 35% (option to 45%)±0.06%
SNF3% – 15%±0.15%
Density1000 – 1160 kg/m³±0.3 kg/m³
Protein2% – 15%±0.15%
Lactose0.01% – 6%±0.2%
Salts0.4% – 1.5%±0.05%
Added water0% – 70%±3%
Sample Temperature5°C  – 40°C±1°C
Sample speed60/30 sec.±0.1sec.
Freezing point-0.4°C to -0.7°C±0.005°C
Electrical conductivity*2-14mS/cm±0.05mS/cm
  Total solids  0-50%
  ±0.17%
pH*0-14±0.05
