OS20-S

Categories

Key Features

High reliability and outstanding performance.
A wide range of speed from 50 to 2200rpm.
Brushless DC motor for long life, maintenance free and explosion proof.
LED screen for monitoring actual speed.
Safety circuits allow for safe stop function in anti-stall or overload conditions.

Specifications	OS20-S
Max. stirring quantity(H2O)	20L
Motor type	brushless DC motor
Motor input power	60W
Motor output power	50W
Voltage	100-240V, 50/60 Hz
Power	70W
Speed range	50-2200rpm
Speed display accuracy	±3rpm
Speed display	LED
Overload protection display	LED lights
Max. torque	40Ncm
Viscosity max.	10000mPas
Chuck range diameter	0.5-10mm
Dimension[WxHxD]	83x220x186mm
Weight	2.8kg
Protection class	IP42
Permissible ambient temperature and humidity	5-40°C, 80%RH
