Key Features
• Digital temperature control with max. temperature up to 280°C
• Digital speed control with max. speed up to 1500rpm
• Stainless steel work plate with ceramic coating provides good chemical resistant performance
• External temperature control is possible by connecting the temperature sensor(PT1000) with an accuracy at ±0.5°C
• LED display shows temperature and speed
• The “HOT” warning will flash when the work plate temperature is above 50°C even if the hotplate is turned off
| Specifications | MS-H280-Pro |
| Work plate Dimension | φ135mm(5 inch) |
| Work plate material | stainless steel cover with ceramic |
| Motor type | Brushless DC motor |
| Motor rating input | 5W |
| Motor rating output | 3W |
| Power | 515W |
| Heating output | 500W |
| Voltage | 100-120/200-240V 50/60Hz |
| Stirring positions | 1 |
| Max. stirring quantity[H2O] | 3L |
| Max. magnetic bar[length] | 50mm |
| Speed range | 200-1500rpm |
| Speed display | LED |
| Temperature display | LED |
| Speed display resolution | ±1rpm |
| Heating temperature range | Room temp.-280, increment 1°C |
| Control accuracy of work plate | ±1°C(<100°C) ±1%(>100°C) |
| Over heat Protection | 320°C |
| Temperature display accuracy | ±1°C |
| External temperature sensor | PT1000 (accuracy ±0.5°C) |
| "Hot" warning | 50°C |
| Protection class | IP21 |
| Dimension [W x D x H] | 150×260×80mm |
| Weight | 1.8kg |
Permissible ambient temperature and humidity
| 5-40℃ 80%RH
|
