Key Features
• Maintenance-free brushless DC motor
• Max speed 1100rpm
• Max.temperature 120°C
• Stainless steel work plate, covered with silicone cushion, provides the excellent performance of heating uniformity and skid resistance
| Specifications | MS-H-S10 |
| Work plate Dimension | 180x450mm |
| Work plate material | Stainless steel with silicone |
| Motor type | Brushless DC motor |
| Motor rating input | 12W |
| Motor rating output | 4W |
| Power | 490W |
| Heating output | 470W |
| Voltage | 100-120/200-240V 50/60Hz |
| Stirring positions | 10 |
| Max. stirring quantity[H2O] | 0.4Lx10 |
| Max. magnetic bar[length] | 40mm |
| Speed range | 0-1100rpm |
| Speed display | scale |
| Temperature display | scale |
| Heating temperature range | Room temp.-120°C |
| Over heat Protection | 140°C |
| Temperature display accuracy | IP42 |
| Dimension [W x D x H] | 182×622×65mm |
| Weight | 3.2kg |
Permissible ambient temperature and humidity
| 5-40℃ 80%RH |
